Trek Top Fuel Top Fuel 8
Serie: Top Fuel - Year: 2016
Where to buy it
Specifications
Drivetrain
| Chain | KMC X10 |
|---|---|
| Crank | Shimano M627, 36/22 |
| Derailleurs | Front: Shimano Deore, low direct mount - Rear: Shimano Deore XT, Shadow Plus |
| Shifters | Shimano SLX, 10-speed |
| Cassette | Shimano HG50, 11-36, 10-speed |
Frameset
| Frame | Alpha Platinum Aluminium, ABP Convert, Full Floater, EVO link, E2 tapered head tube, Mino Link, MicroTruss, internal derailleur and dropper post routing, down tube guard, PF92, Boost148 & G2 Geometry on 29ers, 100mm travel |
|---|---|
| Headset | FSA IS-2 carbon, E2, sealed alloy cartridge |
| Suspensions | Front: Fox Performance 32 Float, FIT4 3-position damper, E2 tapered steerer, Boost110 & G2 Geometry w/51mm offset on 29ers, 100mm travel - Rear: Fox Performance Float, 3-position damper, 6.5x1.5" |
| Bontrager Elite, 31.8mm, 7-degree, Blendr compatible |
Wheels
| Tyres | Bontrager XR1 Expert, Tubeless Ready, aramid bead, 29x2.20" (Bontrager XR2 Expert, Tubeless Ready, aramid bead, 27.5x2.20") |
|---|---|
| Wheels | Bontrager Mustang Elite Tubeless Ready, 15mm front, 12mm rear (Boost110 & Boost148 on 29ers) |
Brakes
| Brakes | Shimano Deore hydraulic disc |
|---|
Components
| Handlebar | Bontrager Race Lite, 31.8mm, 5mm rise |
|---|---|
| Saddle | Bontrager Evoke 2, chromoly rails |
| Seatpost | Bontrager Rhythm Elite, 2-bolt head, 31.6mm, zero offset |
| Stem | Bontrager Elite, 31.8mm, 7-degree, Blendr compatible |
geometry
| Frame size number | Actual frame size | Geometry position | A Seat tube | B Seat tube angle | Effective seat tube angle | C Head tube length | D Head angle | E Effective top tube | F Bottom bracket height | G Bottom bracket drop | H Chainstay length | I Offset | J Trail | K Wheelbase | L Standover | M Frame reach | N Frame stack |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15.5 in | 15.5 in | Low | 39.4 | 69.5 ° | 73.5 ° | 10.0 | 69.9 ° | 55.8 | 33.0 | 2.5 | 42.6 | 4.7 | 8.0 | 106.4 | 75.7 | 39.2 | 56.1 |
