Specifications
Drivetrain
Chain | SRAM XX1 Eagle |
---|---|
Crank | SRAM XX1 Eagle, 34T Direct Mount X-Sync |
Derailleurs | Rear: SRAM XX1 Eagle, Roller Bearing Clutch |
Shifters | SRAM XX1 Eagle, 12-speed |
Cassette | SRAM XG-1295, 10-50, 12-speed |
Frameset
Frame | OCLV Mountain Carbon main frame and stays, ABP, Full Floater, EVO link, E2 tapered head tube, Mino Link, MicroTruss, Control Freak internal routing, Carbon Armor, PF92, Boost148 and G2 Geometry on 29ers, 100mm travel |
---|---|
Headset | Integrated, cartridge bearing, sealed, 1-1/8" top, 1.5" bottom |
Suspensions | Front: Fox Factory 32 Float, Step Cast, FIT4 2-position remote damper, E2 tapered steerer, Kashima Coat, Boost110, G2 Geometry w/51mm offset on 29ers, 100mm travel - Rear: Fox Factory Float, RE:aktiv XC 2-position remote damper, Kashima Coat, tuned by Trek Suspension Lab, 6.5x1.5" |
Bontrager Pro, 31.8mm, 7 degree, Blendr compatible |
Wheels
Tyres | Bontrager XR1 Team Issue, Tubeless Ready, Inner Strength sidewalls, 120 tpi, aramid bead, 29x2.20" (15.5: 27.5x2.20") |
---|---|
Wheels | DT Swiss XMC1200 Carbon, tubeless strips and valves, Boost110 front, Boost148 rear (15.5: 142x12 rear) |
Brakes
Brakes | SRAM Level Ultimate carbon-lever hydraulic disc |
---|
Components
Handlebar | Bontrager XXX, OCLV Carbon, 31.8, zero rise |
---|---|
Saddle | Bontrager Montrose Pro, carbon rails |
Seatpost | Bontrager XXX, OCLV Carbon, 31.6mm, 5mm offset |
Stem | Bontrager Pro, 31.8mm, 7 degree, Blendr compatible |
geometry
Frame size number | Actual frame size | Geometry position | Wheel size | A Seat tube | B Seat tube angle | Effective seat tube angle | C Head tube length | D Head angle | E Effective top tube | F Bottom bracket height | G Bottom bracket drop | H Chainstay length | I Offset | J Trail | K Wheelbase | L Standover | M Frame reach | N Frame stack |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
15.5 in | 15.5 in | Low | 27.5" | 39.4 | 69.5° | 73.5° | 10.0 | 69.9° | 55.8 | 33.0 | 2.5 | 42.7 | 4.7 | 8.0 | 106.4 | 73.2 | 39.2 | 56.1 |
17.5 in | 16.5 in | Low | 29" | 41.9 | 68.5° | 74.0° | 9.0 | 70.0° | 59.3 | 33.0 | 3.9 | 43.5 | 5.1 | 8.0 | 111.1 | 72.4 | 42.7 | 57.7 |
18.5 in | 17.5 in | Low | 29" | 44.5 | 68.5° | 74.0° | 9.0 | 70.0° | 60.9 | 33.0 | 3.9 | 43.5 | 5.1 | 8.0 | 112.7 | 71.9 | 44.3 | 57.7 |
19.5 in | 18.5 in | Low | 29" | 47.0 | 68.5° | 74.0° | 10.0 | 70.0° | 62.5 | 33.0 | 3.9 | 43.5 | 5.1 | 8.0 | 114.4 | 71.9 | 45.7 | 58.7 |
21.5 in | 20.5 in | Low | 29" | 49.5 | 68.5° | 74.0° | 12.0 | 70.0° | 64.6 | 33.0 | 3.9 | 43.5 | 5.1 | 8.0 | 116.6 | 71.9 | 47.2 | 60.6 |
