Specifications
Drivetrain
Chain | Shimano HG60 |
---|---|
Crank | Shimano Deore XT, 36/26 |
Derailleurs | Front: Shimano Deore, high direct mount - Rear: Shimano Deore XT, Shadow Plus |
Shifters | Shimano Deore XT M8000, 11-speed |
Cassette | Shimano Deore XT, 11-42, 11-speed |
Frameset
Frame | Alpha Platinum Aluminium, ABP, Boost148, Knock Block steerer stop, Full Floater, EVO link, E2 tapered head tube, Mino Link, Control Freak internal routing, downtube guard, PF92, ISCG 05, G2 Geometry, 130mm |
---|---|
Headset | Knock Block integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom |
Suspensions | Front: Fox Rhythm 34 Float, Grip adjustable damper, E2 tapered steerer, Boost110, G2 Geometry w/51mm offset, 130mm travel - Rear: Fox Performance Float EVOL, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 210x52.5mm |
Bontrager Line, Knock Block, 35mm, 0 degree |
Wheels
Tyres | Bontrager XR3 Expert, Tubeless Ready, Inner Strength sidewalls, aramid bead, 29x2.40" |
---|---|
Wheels | Bontrager Duster Elite, Tubeless Ready, Boost110 front, Boost148 rear |
Brakes
Brakes | Shimano Deore hydraulic disc |
---|
Components
Handlebar | Bontrager Line, 35mm, 15mm rise, 750mm width |
---|---|
Saddle | Bontrager Evoke 2, chromoly rails |
Seatpost | KS eThirty Integra, remote lever, 2-bolt head, 31.6mm, zero offset, internal routing |
Stem | Bontrager Line, Knock Block, 35mm, 0 degree |
geometry
Frame size number | Actual frame size | Geometry position | Wheel size | A Seat tube | B Seat tube angle | Effective seat tube angle | C Head tube length | D Head angle | E Effective top tube | F Bottom bracket height | G Bottom bracket drop | H Chainstay length | I Offset | J Trail | K Wheelbase | L Standover | M Frame reach | N Frame stack | Frame rise |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
15.5 in | 15.5 in | High | 29" | 39.4 | 66.2° | 74.7° | 10.0 | 67.7° | 56.5 | 33.7 | 3.0 | 43.2 | 5.1 | 9.9 | 112.1 | 76.7 | 39.9 | 60.4 | 60.4 |
17.5 in | 16.5 in | High | 29" | 41.9 | 66.2° | 74.7° | 10.0 | 67.7° | 60.0 | 33.7 | 3.0 | 43.2 | 5.1 | 9.9 | 115.6 | 74.7 | 43.3 | 60.3 | 60.3 |
18.5 in | 17.5 in | High | 29" | 44.0 | 66.2° | 74.7° | 10.0 | 67.7° | 61.7 | 33.7 | 3.0 | 43.2 | 5.1 | 9.9 | 117.3 | 74.2 | 45.0 | 60.3 | 60.3 |
19.5 in | 18.5 in | High | 29" | 47.0 | 66.2° | 74.7° | 10.0 | 67.7° | 63.2 | 33.7 | 3.0 | 43.2 | 5.1 | 9.9 | 118.8 | 73.7 | 46.5 | 60.3 | 60.3 |
21.5 in | 20.5 in | High | 29" | 51.0 | 66.2° | 74.7° | 11.0 | 67.7° | 65.7 | 33.7 | 3.0 | 43.2 | 5.1 | 9.9 | 121.4 | 74.7 | 48.7 | 61.2 | 61.2 |
23 in | 22.0 in | High | 29" | 56.0 | 66.1° | 74.7° | 14.5 | 67.7° | 68.6 | 33.7 | 3.0 | 43.2 | 5.1 | 9.9 | 124.7 | 78.7 | 50.7 | 64.4 | 64.4 |
